    High Reliability Fiber Optic Splitter / SC APC 1x2 PLC Splitter For Local Area Networks

    Ask Lasest Price
    Brand Name : New Light
    Certification : ISO ,ROSH
    Price : 1~30
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 1000000
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    High Reliability Fiber Optic Splitter / SC APC 1x2 PLC Splitter For Local Area Networks

    SC APC 1X2 PLC Singlemode Fiber Optical splitter FTTH SC APC1x2 PLC optical fiber splitter



    Feature:


    * Excellent Mechanical,Small Size
    * High Reliability
    * Low insertion Loss and low Polarization Dependent loss
    * High channel counts
    * Excellent Environmental Stability and Widely Used
    Application:

    Fiber to the point (FTTX)
    Fiber to the home (FTTH)
    Passive optical networks(PON)
    Local area networks (LAN)
    Cable television (CATV)
    Test equipment

    Specification:

    1xN PLC Splitter Specification


    Operating Wavelength(nm)1260~1650
    Fiber TypeG657A1 or as customers' order
    Port Configuration1x21x41x81x161x321x641x128
    Insertion Loss (dB)3.8/4.07.1/7.310.2/10.513.5/13.716.5/16.920.5/21.023.8/24.2
    Loss Uniformity (dB)0.40.60.81.21.52.02.5
    Polarization Dependent Loss(dB)0.20.20.20.250.30.350.4
    Wavelength Dependent Loss(dB)0.30.30.30.50.50.50.5
    Temperature Dependent Loss (-40~85 ) (dB)0.40.40.40.50.50.50.5
    Return Loss (dB)55/50
    Operating Temperature-40~+85
    Directivity (dB)≥ 55
    Storage Temperature-40~+85


    Introduction:

    Single Mode PLC Steel Tube type Fiber Optic Splitter (PLC Splitter) can not work with different ratio rather than it provide a accurate splitting in high-density output (like 8,16,32,64 outputs) However, The most common type of fiber optic splitter splits the output evenly, which is coming out with the same output of light signals. As a result of its great function, Optical splitter is a very important part in passive opitc networks (PON).
