    ADSS Fiber Optic Line 18 Core Self Supporting 100 Span Single Jacket For Aerial

    Ask Lasest Price
    Brand Name : YOFC / Corning
    Model Number : 18 core
    Certification : ISO ,ROSH
    Price : 0.1~100
    Payment Terms : L/C, T/T, Western Union, MoneyGram,paypal
    Supply Ability : 1000000
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    ADSS Fiber Optic Line 18 Core Self Supporting 100 Span Single Jacket For Aerial


    18 core self-supporting 100 Span Single jacket ADSS fiber optic cable for Aerial


    ADSS Cable (All Dielectric Self-supporting Aerial Cable) is loose tube stranded cable.


    Fibers are positioned into loose tube made of high modulus plastics. The tubes are filled with a water-resistant around FRP (Fiber Reinforced Plastic) as a non-metallic central strength member into a compact and circular cable core.


    After the cable core is filled with filling compound, it is covered witha thin polyethylene (PE) inner sheath. After two layers of Aramid yarns are applied in two directions over the inner sheath as strength member, the cable is completed with PE or AT outer sheath.


    After two layers of Aramid yarns are applied in two directions over the inner sheath as strength member, the cable is completed with PE or AT outer sheath.


    Technical Parameters:


    Ref.
    Outer
    Diameter
    (mm)    		Ref.
    Weight
    (kg/km)    		Rec. Daily
    Max.
    Working
    Tension
    (kN)    		Max Allowable

    Working Tension
    (kN)
    		Break
    Strength
    (kN)    		Strength
    Member
    CSA
    (mm2)    		Modulus of
    Elasticity
    CSA
    (kN/mm2)    		Heat
    Expansion
    Coefficient
    (x10- 6/K)    		Suitable Span
    (NESC Standard,m)
    PE
    Jacket    		AT
    Jacket    		ABCD
    12.51251361.54104.67.61.8160100140100
    13.01321422.256157.68.31.5230150200150
    13.31371483.082010.359.451.3300200290200
    13.61451563.6102413.810.81.2370250350250
    13.81471594.5123014.311.81.0420280400280
    14.51641775.4153618.413.60.9480320460320
    14.91711856.75184522.016.40.6570380550380
    15.11791937.95225326.418.00.3670460650460
    15.51902049.0266032.219.10.1750530750510

    Features:

    1.900μm tight buffer fiber,aramid yarn,flame-retardant jacket;

    2.Excellent stripping performance of tight buffer fiber;

    3.Suited to SM fiber and MM fiber(50μm and 62.5 μm).


    Application:

    Adopted to indoor distribution.
    As pigtail of communication equipment.
    Suitable for communication equipment served.
    Suitable for floor connection.


    operate temperature :

    -20℃~+70℃



    Cable construction details


    Fiber typeSingle mode:
    (1)9/125-G652D
    (2)9/125-G655
    (3)9/125-G657A1,G657A2,G657B2,G657B3

    Multimode:
    (4)50/125-OM2
    (5)62.5/125-OM1
    (6)50/125-OM3
    (7)50/125-OM4

    (8)50/125-OM5

    Fiber brandYOFC, Corning, OFS...
    Connector typeSC, LC, FC, ST, E2K, MU, MTRJ, MPO/MTP, SMA, DIN
