100G Fiber Optic Passive Cwdm Module 4CH / 8CH CWDM WDM Mux / Demux Add Drop Multiplexer Devices

FTTH ABS Box 1x16 Channel Fiber Optic CWDM Module with LC Connectors Mux/Demux

We offers a full range of CWDM Mux-Demux and Optical Add Drop Multiplexer (OADM) units to suit all kinds applications and network solutions. Some most common ones are: Gigabit & 10G Ethernet, SDH/SONET, ATM, ESCON, Fibre Channel, FTTx and CATV.

Parameters	Value	Unit
Wavelength	1270~1610	nm
Insertion Loss	3.0	dB
Isolation	≥30 / ≥40	dB
Return Loss	>50	dB
Temperature sensitivity	<0.005	dB/℃
PDL	<0.10	dB
PMD	<0.10	Ps
Directivity	≥50	dB
Max input power	300	W
Working temperature	-20~+70	°C
Storage temperature	-40~+85	°C
Fiber type	SMF-28e
Package Dimention	1008010 ABS Box	mm
Pigtail	250um/900um/2.0mm/3.0mm	mm

1×N CWDM Mux/Demux Module

OADM

ITU

Channels Number

Application Type

Central Wavelength

Fiber diameter

Fiber Length

Connector

1=100G

2=200G

4=4 Channels

8=8 Channels

16=16 Channels

M=Mux
D=DeMux

41=1410nm

43=1430nm

45=1450nm

47=1470nm

49=1490nm

51=1510nm
53=1530nm
55=1550nm
57=1570nm
59=1590nm

1=250um

2=900um

3=2.0mm

4=3.0mm

XX=Other

05=0.5m

10=1.0m

15=1.5m

20=2.0m

XX=Other

0=None
1=FC/APC
2=FC/PC
3=SC/APC
4=SC/PC
5=ST
6=LC

X=Other

Features:

Low Insertion Loss
High Isolation
Low PDL
Compact Design
Good channel-to-channel uniformity
Wide Operating Wavelength: From 1260nm to 1620nm
Wide Operating Temperature: From -40℃ to 85℃
High Reliability and Stability

Applications:

CWDM System

Add/Drop

PON Networks

CATV Links

Compliance:

Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
RoHS

Packaging : bags&carton box

Shipping: International Express: Fedex, DHL, UPS, TNT and EMS , by air or by sea ..If you have another

preferred carrier, please notify us in advance.

Delivery and payment

1. T/T/ , PAYPAL , WESTEN UNION , MONEY GRAM , L/C .
2. 30% deposit in advance , 70% balance paid before delivery .
