    Single Mode Simplex Fiber Optic Connectos SC / FC / LC / ST / E2000

    Ask Lasest Price
    Brand Name : New Light
    Model Number : ST
    Certification : CE / ISO / RoHS
    Price : 0.1~100
    Payment Terms : T/T, Western Union, MoneyGram, paypal
    Supply Ability : 10,000 pcs per month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    Single Mode Simplex Fiber Optic Connectos SC / FC / LC / ST / E2000

    single mode SC / FC / LC / ST / E2000 simplex fiber optic connector


    LC connector – simplex and duplex – push and latch – 1.25mm ferrule . Available in single mode and multimode.
    Externally LC connectors resemble a standard RJ45 telephone jack. Internally they resemble a miniature version of the SC connector. LC connectors use a 1.25mm ceramic (zirconia) ferrule instead of the 2.5mm ferrule. LC connectors are licensed by Lucent and incorporate a push-and-latch design providing pull-proof stability in system rack mounts. Highly favored for single mode applications

    single mode SC / FC / LC / ST / E2000 simplex fiber optic connector Both examples shown above are for single fiber cable (simplex) which is easy to install. However there are also duplex and multi-fiber connector designs. Below are loosely divided family types of fiber connectors which sometimes overlap.


    Attributes


    Features of good connector design:
    Low insertion loss
    High return loss (low amounts of reflection at the interface)
    Ease of installation
    Low cost
    Reliability
    Low environmental sensitivity
    Ease of use

    connector typesingle mode / multimode
    colorblue / Green
    cable0.9/2.0/3.0


    Features:


    ---Low insertion loss and back reflection loss
    ---Ferrule end surface pre-domed
    ---Precision anti-rotation key
    ---Nickel plated brass body
    ---Telcordia style boots
    ---Free-floating ceramic ferrule

    Parameter


    products nameOEM / ODM 3.0mm Fiber Optic ST Connector For Indoor Distribution Patch Cord
    mode typesingle mode / multi mode
    cable diameter3.0 mm
    insertion loss≤ 0.3dB ( low insertion loss can be ≤ 0.35dB )
    return loss≥60 dB
    wave length1310/1550
    ferrule materialCeramic
    operater temperature-40~ +85℃
    OEM/ODMacceptable
    warranty3 years after delivery
    Delivery time2-15 working days ( according to your quantity )

    more connector for reference



    Connector typeLC / SC / FC / FC / E2000 / MPO /MTRJ /SMA
    Mode typesingle mode or multimode
    Cable type0.9 / 2.0 / 3.0 mm

    How to order


    1. Connector type : SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
    2. Mode type : single mode ( UPC and APC ) / multi mode ( PC )
    3. Cable diameter : 0.9 / 2.0 / 3.0 mm ( can customized other diameter )
    4. Coating material : PVC / LSZH
    5. fiber count : simple / duplex / 4 core / 6core / 8 core /12 core / 24core/48 core / 96 core and so on
    6. Cable type : G652D / G657A1 / G657A2 /G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 /OM5
    7. Patch cord length : according to your requirement
    8.MPO/MTP connector should let us know which method ( A type / B type /C type ), male or female , fiber count (4/8/12/16/24/32 fiber )
